| Output Power | 20W 30W 50W |
| Wave Length | 1050-1075 nm |
| Power Adjustment | 0 to 100% |
| Cooling | Air Cooled |
| Min Line Width | Min.0.03 mm (Depend On material) |
| Max Speed | Max 10000 mm/s (Max.Linear Speed) |
| Marking Depth | 0.01 0.3 mm (Depend on Material) |
| Min Character Height | 0.5 mm |
| Marking Range | 150 mm X 150 mm (Optional : 100 mm,175 mm,200mm,270mm,300mm) |
| Support Format | PLT,DXF,BMP Files etc. Using SHX TTF Character Storage directly |
| Single Pusle energy(mj) | 1.0@20KHz 1.0@30KHz 1.0@50KHz 1.0@KHz |
| Repetition Frequency Range | 1.6-1000KHz |
| Output Power Stability | <3% |
| Beam Quailty (M) | <2.0 |
| Pulse Width (ns) | 4-200 |
| Power Supply | AC 220 Volt |
| Max Power Consumption (laser Source) | 220 Watt 250 Watt 350 Watt 500Watt |
SPARK-ON is a leading name in CNC Fiber Laser Cutting Technology, recognized for its high performance, reliability, and productivity. We offer top-quality machinery supported by major global manufacturers such as IPG, Raycus, Maxphotonics, and N-light. Our commitment to excellent after-sales support and extensive spare parts inventory ensures minimal downtime and maximized profitability. We pride ourselves on delivering cutting-edge technology and exceptional service. Choose SPARK-ON for advanced machinery and reliable support. Your success is our success—let’s achieve it together.
